Ausführliche Beschreibung der vorgewählten Orgel
Bild: Stichting Vrienden Vollebregt
Sassenheim, Nederland (Zuid-Holland) - Sint Pancratiuskerk
Gemeinde: Teylingen
Adresse: Hoofdstraat 186, 2171 BM, Sassenheim
Website: http://www.rkpancratius.nl/
Beschreibung nr.: 1006535.
Gebaut von: firma P.C. Bik (1947)
Die Orgel enthält älteren Material: Pipes aus 1873 von Johannes J. Vollebregt & Zn.
Technische Daten
Disposition
Hoofdwerk (C-g'''): Bourdon 16', Prestant 8', Salicionaal 8', Fluit Harmoniek 8' - 2018, Holpijp 8', Octaaf 4', Fluit 4', Octaaf 2', Mixtuur II-IV sterk, Trompet 8' - 2015.
Zwelwerk (C-g'''): Viola di Gamba 8', Vox Célèste 8', Bourdon 8', Salicet 4', Roerfluit 4', Speelfluit 2' - 2018, Basson-Hautbois 8' - Mutin/2018.
Pedaal (C-f'): Contrabas 16', Subbas 16' - 2014, Open Bas 8', Gedekt 8' - 2014; extension.
Koppeln: Manuaal I - Manuaal II, Manuaal I - Manuaal II 4', Manuaal I - Manuaal II 16', Manuaal I - Manuaal I 4', Pedaal - Manuaal I, Pedaal - Manuaal II.
Nebenregister und Spielhilfen: Tongwerken af, Vaste combinaties (p - mf - mf - f - t), 1 vrije combinatie, Automatische pedaalomschakeling, Generaal-Crescendo.
Bild: Stichting Vrienden Vollebregt
Sassenheim, Nederland (Zuid-Holland) - Sint Pancratiuskerk
Gemeinde: Teylingen
Adresse: Hoofdstraat 186, 2171 BM, Sassenheim
Website: http://www.rkpancratius.nl/
Beschreibung nr.: 1006535.
Gebaut von: firma P.C. Bik (1947)
Die Orgel enthält älteren Material: Pipes aus 1873 von Johannes J. Vollebregt & Zn.
| Jahr | Orgelbauer | Opus | Aktivität | 1873 | Johannes J. Vollebregt & Zn. | Neubau | 1947 | firma P.C. Bik | Neubau | 1997 | firma P.C. Bik | Verschiedene Tätigkeiten | 1997 | Flentrop Orgelbouw | Verschiedene Tätigkeiten | 2012 | Adema's Kerkorgelbouw | Verschiedene Tätigkeiten |
- In 1873 an organ was built by the Vollebregt firm for the Sint Pancratiuskerk in Sassenheim. The instrument was completely rebuilt in 1946/1947 by P.C. Bik. The intention was to build a two-manual organ, but it was not completed. Many stops were only prepared for. In 1972 the organ was taken out of use as a result of the installation of a Vermeulen choir organ on the priest's choir. However, it remained present in the choir loft.
- In 1996/1997 the instrument was cleaned by mr. K. Gütz, assisted by Bik. Flentrop tuned the organ in 1997. In 2012 the organ was re-voiced and overhauled by the company Adema.
- In 2003 a foundation was established to preserve the organ and acquire funds for completion of the instrument. The first action was to connect the prospect pipes of the Contrabas 16' and Open bas 8' to the pedal. These pipes were not speaking until this moment. The swell box has been improved, and in 2012 a case was constructed for the main organ. In 2014, the pedal was expanded with a Subbas 16' and Gedekt 8', in 2015 a new Trompet was installed, replacing the existing Trompet from 1947. The next expansion was realized in August 2018 with the installation of Basson-Hautbois (from Mutin) and a Speelfluit 2' on the Zwelwerk, and a Fluit Harmoniek 8' on the Hoofdwerk.
Technische Daten
| Anzahl Register pro Manual | |
| - Hoofdwerk | 10 |
| - Zwelwerk | 7 |
| - Pedaal | 4 |
| Gesamtzahl der Stimmen | 21 |
| Tastentraktur | Electropneumatic |
| Registertraktur | Electropneumatic |
| Windlade(n) | Cone chests |
| Tonhöhe | a' = 440 Hz |
| Temperatur | Equal temperament |
Disposition
Hoofdwerk (C-g'''): Bourdon 16', Prestant 8', Salicionaal 8', Fluit Harmoniek 8' - 2018, Holpijp 8', Octaaf 4', Fluit 4', Octaaf 2', Mixtuur II-IV sterk, Trompet 8' - 2015.
Zwelwerk (C-g'''): Viola di Gamba 8', Vox Célèste 8', Bourdon 8', Salicet 4', Roerfluit 4', Speelfluit 2' - 2018, Basson-Hautbois 8' - Mutin/2018.
Pedaal (C-f'): Contrabas 16', Subbas 16' - 2014, Open Bas 8', Gedekt 8' - 2014; extension.
Koppeln: Manuaal I - Manuaal II, Manuaal I - Manuaal II 4', Manuaal I - Manuaal II 16', Manuaal I - Manuaal I 4', Pedaal - Manuaal I, Pedaal - Manuaal II.
Nebenregister und Spielhilfen: Tongwerken af, Vaste combinaties (p - mf - mf - f - t), 1 vrije combinatie, Automatische pedaalomschakeling, Generaal-Crescendo.
| Übrige dispositiondaten | |
|---|---|
| Mehrere dispositionen |
The specification from 1947 was (including the prepared stops): Manuaal I: Prestant 16' - prepared, Bourdon 16', Prestant 8', Salicionaal 8', Violoncel 8' - prepared, Holpijp 8', Octaaf 4', Fluit 4', Octaaf 2', Mixtuur II-IV sterk, Fagot 16' - prepared, Trompet 8', Trompet 4' - prepared. Manuaal II (in zwelkast): Vioolprestant 8' - prepared, Flûte Harmonique 8' - prepared, Bourdon 8', Viola di Gamba 8', Vox Célèste 8', Aeoline 8' - prepared, Salicet 4', Roerfluit 4', Quint 2 2/3' - prepared, Terts 1 3/5' - prepared, Hobo 8' - prepared, Tremolo - prepared. Pedaal: Contrabas 16' - prepared, Subbas 16' - prepared, Quint 10 2/3' - prepared, Octaafbas 8' - prepared, Gedekt 8' - prepared, Prestant 4' - prepared, Bazuin 16' - prepared. Couplers: Manuaal I - Manuaal II, Manuaal I - Manuaal II 4', Manuaal I - Manuaal II 16', Manuaal I - Manuaal I 4', Pedaal - Manuaal I, Pedaal - Manuaal II. Accessories: Tongwerken af, Vaste combinaties (p - mf - mf - f - t), 1 vrije combinatie, Automatische pedaalomschakeling, Generaal-Crescendo. |
